产品特征：
温度范围：-40℃~+70℃
内胶：SBR 黑色光滑
外胶：天然橡胶/丁二烯橡胶
颜色：黑色
软管类型：D
Temperature range:-40℃ up to +70℃
Internal lining:SBR,black ,smooth
External over:NR/BR,black,smooth,high abrasion-proof,weather-resistant NR/BR, NR/BR;
Color:black
Inlays:textile fabric
|
Inner (mm) |
Wall (mm) |
Outer (mm) |
WP (BAR) |
BP (BAR) |
BENDING RADIUS (mm) |
WEIGTH (G/M) |
HOSE LENGTH (M) |
| 13 | 6 | 25 | 250 | 625 | 65 | 440 | 40 |
| 13 | 6 | 25 | 250 | 625 | 65 | 440 | 60 |
| 13 | 6 | 25 | 250 | 625 | 65 | 440 | 80 |
| 13 | 6 | 25 | 250 | 625 | 65 | 440 | 120 |
| 19 | 6 | 31 | 250 | 625 | 90 | 555 | 80 |
| 19 | 6 | 31 | 250 | 625 | 90 | 555 | 120 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 40 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 60 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 80 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 120 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 160 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 180 |
| 25 | 7 | 39 | 250 | 625 | 100 | 780 | 200 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 40 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 60 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 80 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 120 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 160 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 180 |
| 32 | 8 | 48 | 250 | 625 | 130 | 1060 | 200 |
